MAKCNC Vertical CNC Machining Center MV970 is a small and medium-sized fixed-column vertical machining center, which adopts mechanical and electrical integration design, beautiful appearance, and can perform precision cutting. After the workpiece is clamped once, the machine tool can automatically and continuously complete various processes such as milling, drilling, boring, expanding, reaming, countersinking, and tapping.

This machine is suitable for multi-variety processing of complex parts such as medium and small boxes, plates, discs, shells, etc. It is widely used in auto parts, valves, engineering machinery, IT equipment, optical equipment, medical equipment and aviation Aerospace and other industries.

all　Machine : The whole machine is fixed by columns, and the structure of cross sliding table is movable. The whole machine has high rigidity, high stability and high reliability. The machine tool has the function of chip flushing with large flow . The fully enclosed protection has a beautiful appearance and is easy to operate and maintain.

Spindle box: Taiwan 's high-speed spindle is adopted, and the spindle adopts BT40 specification.

Tool magazine: The tool magazine adopts a disc-type tool magazine with reliable quality and stable performance .

Drive: The three-axis motor and the high-precision ball screw are directly connected and driven. The ball screw is pre-stretched and installed to further improve the transmission rigidity and positioning accuracy. The three linear coordinate axes all adopt linear roller guideways,

System: Equipped with high-performance Japanese FANUC CNC system, which ensures the stability of the machine tool control, and also guarantees the CNC processing functions and auxiliary functions required by users.

The quality of all parts and components of machine tool processing and assembly conforms to the product drawings and related technical requirements, and its safety standard conforms to the relevant provisions of GB15760-2004 "General Technical Conditions for Safety Protection of Metal Cutting Machine Tools", and its precision standard conforms to GB/T17421-2000 "Machine Tool Inspection "General Rules" and JB/T8771-1998 " Machining Center Inspection Conditions " related regulations.
